Product Introduction
The YEJ Series Electromagnetic Brake Three-Phase Asynchronous Motor is an integrated electromechanical power product designed and manufactured in strict accordance with the machinery industry standard JB/T 6456. It incorporates a non-excitation action (power-off brake) type disc electromagnetic brake at the non-shaft extension end of a standard three-phase asynchronous motor. This series effectively addresses the issues of continued inertial operation or inability to achieve precise positioning after power-off in general motors, enabling rapid stopping and accurate holding functions. It is an ideal drive unit for various automated equipment requiring fast response, secure positioning, and prevention of slippage.
Power-off Safety Braking: It employs a non-excitation braking (i.e., power-off braking) method. When the motor is powered and running, the brake automatically releases. When the power is cut off, the brake immediately engages the brake disc under spring force, generating braking torque to quickly stop and lock the motor shaft. This design adheres to the “power-loss safety” principle, providing safety protection in case of unexpected power loss.
High Electromechanical Integration: The brake and motor form a compact, robust integrated unit. The structure is unified, with installation dimensions highly compatible with standard motors of the same frame size, saving installation space and facilitating wiring.
Rapid Braking Response: The brake responds sensitively with short braking times, meeting the demands of frequent starts/stops and quick positioning, thereby improving equipment operational efficiency.
Dual Protection Ratings: The main motor body has a protection rating of IP44, effectively preventing dust and water splashes. The brake section has a protection rating of IP23, preventing ingress of solid objects larger than 12mm and water drops within 60° from vertical, making it suitable for common industrial environments.
Reliable Cooling and Insulation: Utilizing the IC411 (self-ventilated) cooling method and a Class B (130°C) insulation system, it ensures stable operation and long service life under continuous or frequent start/stop conditions.
Execution Standard: JB/T 6456
Frame Size Range: Covers center heights from H80 to H225.
Rated Power Supply: Rated voltage 380V, rated frequency 50Hz (the brake coil voltage is typically DC 99V, 170V, etc., converted from the 380V AC supply via a built-in rectifier bridge; specific details require confirmation).
Braking Method: Non-excitation (power-off braking).
Insulation System: Class B insulation.
Protection Rating: Main motor body IP44, brake section IP23.
Cooling Method: IC411 (self-ventilated cooling).
Operating Environment:
Altitude: ≤ 1000 meters
Ambient temperature: -15°C to +40°C
YEJ series motors are widely used in automated equipment requiring rapid stopping, precise positioning, and secure holding, such as:
- Material Handling Equipment: Conveyors, hoists, lifting platforms, and electric hoists to prevent slippage or falling after power loss.
- Packaging and Printing Machinery: Bag-making machines, labelers, and printing presses for accurate pattern alignment and stopping.
- Machine Tool Attachments: CNC indexing heads and rotary tables to ensure precise fixation of machining angles.
- Production Line Equipment: Assembly lines and turnover mechanisms for accurate station positioning.
- Textile and Chemical Machinery: Winding equipment and mixers to control winding diameter and stop positions.
- Construction Machinery: Small winches and building material processing equipment.
We offer a wide range of YEJ Series Electromagnetic Brake Three-Phase Asynchronous Motor models for your selection.
